Currently, trends such as miniaturization of devices and new architectures are constantly driving the demand for new connectivity modes. Therefore, connector and other component manufacturers hope to provide their customers with more specification choices.

Haoting launches its latest har flex ®  The product line provides a more flexible and reliable solution for connecting printed circuit boards (PCBs), making it easier than ever before! Use Haoting's latest har flex ®  Product upgrade your PCB connection, combining reliability and flexibility, distance is no longer a challenge.

The ideal choice for high-performance requirements

Haoting's new har flex ®   The adapter is very suitable for connecting circuit boards with large components, such as capacitors located between stacked circuit boards. These capacitors are typically used in applications that require slow speed and high torque, such as robotic arms, industrial motors, and high torque machines.

Easy to use connection scheme

The biggest difference of the new product is the newly added latch function. Through this design, the connector can achieve a more stable connection, ensuring safety and reliability during long-term use. To achieve this permanent locking function, users only need to use our latest designed female connector to easily complete a secure connection, avoiding loosening caused by vibration or external forces.

har-flex ®   Overview of New Product Advantages

1. Common pole numbers: Provide commonly used sizes (12, 26, 50, 68, and 80 poles)

2. Longer spacing: Can connect stacked PCBs with a spacing of 20 to 40 mm

3. Safety latch: One side of the adapter has a latch function to ensure a sturdy and permanent connection

4. Controlled disconnection: If you need to disconnect, it will disconnect at the correct point, which is particularly important for connections through walls or hard to reach areas

5. Sealed box design: This design helps to maintain a safe distance from any wire, making its use safer

har-flex ®  Series adapts to more flexible scenarios

For applications that require a large distance between circuit boards, Haoting's har flex ®  The series also offers IDC ribbon cable components for connecting circuit board distances of 8 to 20mm. In addition, for devices with higher requirements, Haoting's products can support multiple configurations ranging from 6 to 100 needles, ensuring flexibility and efficiency in different application scenarios.

In order to maintain the necessary flexibility, Haoting's har flex ®  The series has reserved a small interface with a spacing of 1.27 millimeters, so, har-flex ®  The series can be applied to almost every small application scenario while still maintaining very robust characteristics. According to the required application type, users can freely choose 6-100 pins, and whether the accessories use SMT surface mount technology or additional THR through-hole reflow process.
